4 Port PoE + 2 LAN, 65W power supply

Quantity
(0 available)
Total Price
৳4,200.00
Contact Us
MESSAGE ON WHATSAPP CALL TO ORDER ORDER NOW
Top Selling Products
Description

Brand: Newbridge

Model: ND-MP0420

  1.  4*10/100Mbps PoE ports, 2*10/100Mbps uplink port
  2.  Support IEEE802.3af/at
  3.  Support restrains network storm, VLAN function
  4.  Support Max Transmission distance up to 250m with PoE Power
  5.  All port supported by MDI/MDIX auto flip and self-negotiation
  6.  Built-in power supply;
  7.  Maximum power of single PoE port: 30 W;
  8.  Maximum PoE power: 65W;
  9.  Adopts store-and-forward architecture;
  10.  Fan less, natural cooling, small, compact and quiet design, suitable for desktop or wall
  11.  Support lightning protection 4kV



ModelND-MP0420
ChipsetChip BrandsChip Model
JLSemiJL5108
PowerPower Adapter VoltageAC 110V-240V
Consumption65W(52V 1.44A)


Network Connector		Network PortPoE Ethernet Port1～4 Port : 10/100Mbps
Ethernet portUplink Port : 10/100Mbps

Transmission Distance		1～4 Port :
100Mbps:0~100m;
10Mbps: 0~250m;
Uplink Port : 0 ~ 100m
Transmission MediumCat5/5e/6 standard network cable



Network Switch		Network StandardIEEE802.3/802.3u,
IEEE802.3x,
IEEE802.ab
Switching Capacity1.2Gbps
Packet Buffer Memory1Mbits
Throughput0.8928Mpps
MAC Table1K

Packet Forwarding rate		10Mbps:14880pps/port             100Mbps: 148800pps/port

Power Over Ethernet		PoE StandardIEEE 802.3af/at
PoE Power Supply1/2 + ,3/6- ;4 core power supply
PoE Poweraf=15.4W,at=30W for each port

RJ45 port

Port Function		Power priority mechanism,
fast and forward,
MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode

LED Indicator
LED Indicator		LINK/ACT.100Mbps;
PoE Status Indicator;
 Power indicator;Extender

Environmental		Working temperature0℃~55℃
Relative Humidity20~95%
Storage temperature-20℃~70℃

Mechanical		Dimension (L×W×H)190mm*125mm*38mm
ColorBlack
Weight0.76kg
